H3C SFP-XG-SX-MM850-D 10G SFP+ SR Optical Transceiver
1. Product Overview
The H3C SFP-XG-SX-MM850-D is a high-performance, hot-pluggable SFP+ optical transceiver module designed for 10 Gigabit Ethernet
applications. It operates at a wavelength of 850nm over multi-mode
fiber (MMF), supporting a link length of up to 300 meters on
OM3/OM4 cable. This module is fully compliant with the SFP+ MSA and
IEEE 802.3ae 10GBASE-SR standards, ensuring seamless
interoperability with a wide range of H3C networking equipment, including the LSQM2GT24PTSSC0 interface
card. It is an ideal, cost-effective solution for high-speed data
center interconnects, enterprise backbone networks, and storage
area networks (SAN).
2. Key Characteristics
- Data Rate: 10.3125 Gbps (10GBASE-SR)
- Wavelength: 850nm
- LC Duplex Connector
- Maximum Reach: 300m on 50/125μm OM3/OM4 MMF; 33m on 62.5/125μm MMF
- Low Power Consumption: < 1W
- Hot-pluggable SFP+ Form Factor
- Digital Diagnostic Monitoring (DDM) via I2C Interface
- Compliant with IEEE 802.3ae, SFF-8431, SFF-8472
- RoHS Compliant
3. Technology & Standards
This SFP+ transceiver leverages VCSEL (Vertical-Cavity Surface-Emitting
Laser) technology for highly reliable and efficient short-range
optical transmission. It strictly adheres to critical industry
standards including IEEE 802.3ae for 10GBASE-SR, the SFP+
Multi-Source Agreement (MSA), and the Digital Diagnostic Monitoring
(DDM) specifications defined in SFF-8472, providing real-time
monitoring of temperature, voltage, laser bias current, and
transmitted/received optical power.
4. Working Principle
The electrical 10G data signal from the host switch's SFP+ port is received by the transceiver's driver IC. The IC drives an
850nm VCSEL laser diode, which converts the electrical signals into
optical signals. These light pulses are transmitted through a
multi-mode fiber via an LC connector. At the receiving end, a
photodiode detector converts the incoming optical signals back into
electrical data signals for the host system to process. The
built-in DDM controller continuously monitors the module's
operational parameters.
5. Application & Usage
The H3C SFP-XG-SX-MM850-D is deployed in diverse environments requiring high-bandwidth,
short-reach connections:
- Data Centers: For top-of-rack (ToR) to end-of-row (EoR) switch connections and
server aggregation.
- Enterprise Networks: Building backbone links and connecting high-performance
workgroups.
- Storage Area Networks (SAN): Interconnecting switches and storage devices in Fibre Channel
environments.
- High-Performance Computing (HPC): Providing low-latency, high-speed cluster interconnects.
6. Specifications & Selection Guide
| Parameter | Specification |
|---|
| Product Model | SFP-XG-SX-MM850-D |
| Form Factor | SFP+ |
| Interface | LC Duplex |
| Data Rate | 10.3125 Gbps |
| Max Distance | 300m (50/125μm OM3/OM4), 33m (62.5/125μm OM1) |
| Wavelength | 850nm |
| Diagnostics | Digital Diagnostic Monitoring (DDM) |
| Power Consumption | < 1W |
| Operating Temperature | 0°C to 70°C (32°F to 158°F) |
| Compatibility | H3C S7500E & S7500X Series Switches (e.g., LSQM2GT24PTSSC0 card) |
7. Advantages & Selling Points
- Proven Reliability: Manufactured to H3C's stringent quality standards, ensuring stable performance in
demanding 24/7 environments.
- Cost-Efficiency: Offers the most economical solution for 10G short-reach
applications compared to single-mode alternatives.
- Full Compliance: Guaranteed interoperability with H3C switches, eliminating compatibility concerns.
- Enhanced Monitoring: DDM features enable proactive network management and simplified
troubleshooting.
- Low Latency: Ideal for latency-sensitive applications like financial trading
and HPC.
8. Service & Support
We provide a comprehensive service package for all our H3C products. This includes a default lifetime warranty on the SFP-XG-SX-MM850-D module. We maintain over $10M in inventory to ensure rapid
shipment, typically within 24 hours for in-stock items. Our
technical support team, with over a decade of experience, is
available 24/7 to assist with pre-sales consultations, installation
guidance, and post-sales troubleshooting to ensure seamless
integration into your network.
9. Frequently Asked Questions (FAQ)
Q: Is this module compatible with my H3C S7500X switch?
A: Yes, the SFP-XG-SX-MM850-D is fully compatible with H3C S7500E and S7500X series switches, specifically on the
10GBASE-R-SFP+ ports of cards like the LSQM2GT24PTSSC0.
Q: What is the difference between this SR module and an LR module?
A: The SR (Short Range) module uses multi-mode fiber for distances
up to 400m. The LR (Long Range) module uses single-mode fiber for
distances up to 10km. Choose based on your distance requirements.
Q: Does this transceiver support DDM/DOM?
A: Yes, the SFP-XG-SX-MM850-D supports Digital Diagnostic Monitoring (DDM), allowing you to
monitor real-time parameters like optical power and temperature.
Q: What type of fiber cable should I use?
A: For best performance and to achieve the full 300m distance, use
OM3 or OM4 50/125μm laser-optimized multi-mode fiber patches with
LC connectors.
10. Precautions
- Compatibility: Verify compatibility with your specific H3C switch model and software version (Requires H3C Comware Software
Release 7150 or later).
- Fiber Type: Ensure the use of correct multi-mode fiber (OM3/OM4 for 300m).
Using 62.5/125μm fiber will limit the distance to 33m.
- Handling: Avoid touching the LC connector ferrules. Always use clean fiber
optic cleaning tools.
- Static & ESD: Handle with proper ESD precautions. Use an ESD wrist strap when
installing or removing the module.
- Environment: Operate and store within the specified temperature and humidity
ranges to ensure longevity and performance.
